GALION
A BALE TRAILER TAKING ACTION
- Range from 6 to 11.7 m
- Trailed or semi‑mounted models
- Paint protection with hammered effect
- Front/rear ladders or retractable side ladders
GTP80D10
GTP80D14
GTP100D14
GTP100T21
GTP117T21
GSP60S07
GSP80D14
GSP100D14
GSP100T24
GSP117T24
Suspension leaves
Suspension leaves under the axles to limit the trailer height and facilitate traction
Semi-Mounted
Narrow drawbar
Narrow drawbar with central parking stand.
Sprung drawbar
Sprung drawbar with height adjustment.
Adjustable rail
Adjustable rail with self-lubricating ertalon for drawbar suspension.
Eyelets
Wide choice of bolted eyelets on semi-mounted models
(A) Ø 50 mm swivel eye
(B) Ø 80 mm knee-joint eyelet
(C) Ø 50 mm fixed eyelet (standard)
(D) Ø 40 mm fixed eyelet
Welded Ø 40 mm flat eye on trailed models
Various rear hitches to hitch a second bale trailer/low loader
Fixed rear hitch with or without electrical plug.
Rear swivel hitch with or without electrical plug.
Automatic rear swivel hitch with or without electrical plug.
Oversized tubular reinforcement
Oversized tubular reinforcement of the chassis on trailed Galion.
Brakes
Air brakes
Dual-line hydraulic brakes
Dual brakes (hydraulic and air brakes)
Air brakes proportional to the load
Mudguards
Thermoplastic mudguards
Wheel chocks
Wheel chocks
Document tube
Document tube
Polyethylene box
Polyethylene box 600 x 480 x 400 mm.
Spare wheel with winch
Spare wheel with winch
Profile of outer stringer
Profile of outer stringer
Lighting
(A) Side marker lights
(B) End outline marker lamps
Work lights or reversing lights
Work lights or reversing lights
Protection with 2-component paint (2K industrial quality)
Protection with 2-component paint (2K industrial quality)
(A) Floor in chequered plate with a 2.5 cm edge to better hold the load.
(B) Automatic shot-blasting with 20 turbines (2,300 kg shot/min).
(C) 2K primer coat applied directly after blasting + flash-off before applying the finish.
(D) Finish with 2K paint and hammered effect.
2 strap tensioners
2 strap tensioners at the back possible.
Numerous lashing points
Numerous lashing points
Front and rear ladders
Removable, multiposition front and rear ladders.
Retractable side ladders
Retractable side ladders with front and rear brackets that reduce the useful length by 114 mm (available only on 8-m and 10-m models).
Self-unfolding extensions for side ladders
Self-unfolding extensions for side ladders to automatically secure the upper bales whatever their height (70 to 120 cm) • Patented system.
